Cobot Gripper IR130-100C

Name: Cobot Gripper IR130-100C
Brand: Inlux Robotics
Price: 3395.00 EUR
Availability: InStock

€3.395,00

Product variants

Description

The IR130-100C Gripper is an optional addition, ideal for applications that require gripping and releasing objects. The position, speed, and gripping force of the gripper can be easily adjusted via the gripper's software.

This gripper is perfect for picking up circular objects. With the gripper's wide range, you can pick up both small and large diameter products.

Specifications & Included

Specifications:

Range (diameter): 40-170mm
Force per clamp: 30-100 N
Total force: 90-300N

Included:

Cobot Gripper IR130-100C
Gripper Fingers
Gripper Cable
Gripper Software USB Stick

Downloads

Centric Three Finger STEP 3D Model

Would you like to order?

Order: You can place your order directly through our website or you can submit a request by contacting us.

Prices Excluding VAT: 0% VAT for companies in the EU, excluding the Netherlands, intra-community delivery.

Delivery Time: The delivery time depends on the item. If the item is in stock, it will be shipped within 1 to 2 business days.

Request Quote

FAQs

Check out our FAQs page for even more questions and answers.

How is this gripper controlled via Fairino?

The gripper is controlled via the controller's I/O. The supplied cable is routed along the robot arm and connected to the control box. The gripper supports three fixed positions and provides position feedback.

Can two grippers be operated simultaneously?

Yes, multiple grippers can be connected directly to the control box without a splitter.

Is combination with a torque sensor possible?

Yes, this gripper can be directly combined with a torque sensor.

Can custom fingers be installed?

Yes, the standard fingers are replaceable.
